3032 TX Smart
- Max useful power - 25.35 kW (34 HP) PTO Power
- Max Road Speed (33.06 KMPH @ Rated RPM)
- Constant Mesh AFD Side Shift
- SOFTEK Clutch
- HP Hydraulic with Lift-O-Matic & 1500 kg Lift Capacity
- Multisensing with DRC Valve
- Real Oil Immersed Brakes
Ambica Global Trade | New Holland | Jetalpur
Ambica Global Trade | New Holland | Jetalpur
Models
Explore available models
TECHNICAL SPECIFICATIONS
3032 TX Smart
Engine Model
T-IIIA, S 324
Engine Power
27.59kW (Cat) 37 HP Cat.
Technical specifications
| 3032 TX Smart | |
| Engine | |
| Engine Model | T-IIIA, S 324 |
| Engine Type | Naturally Aspirated |
| Engine Power | 27.59kW (Cat) 37 HP Cat. |
| Rated RPM | 2000 |
| Air Cleaner | |
| Air Cleaner Type | Oil bath type with Pre-cleaner |
| Transmission | |
| Clutch | Single Clutch |
| Type | Constant Mesh AFD Side Shift |
| Gear Box | 8F+2R |
| PTO | |
| PTO Type | Multi Speed & Reverse PTO |
| PTO HP | 33 HP (24.6 kW) |
| Hydraulics | |
| Lift Capacity | 1100 kg |
| Lift-O-Matic | Yes |
| Rear Axle | |
| Rear Axle Type | Straight Axle Planetry Drive |
| Brakes | |
| Brake Type | Oil Immersed Multi Disc Brake |
| Steering | |
| Information | Mechanical /Power Steering |
| Tyre | |
| Front | 6 in x 16 in (152.4 mm x 406.4 mm) |
| Rear | 13.6 in x 28 in (345.44 mm x 711.2 mm) |
| Electricals | |
| Battery & Alternator | 75 Ah & 35 Amp |
| Dimension | |
| Overall Length (mm) | 3410 |
| Width (mm) | 1790 |
| Height (mm) | 2260 |
| Wheelbase (mm) | 1920 |
| Ground Clearance (mm) | 385 |
| Weight (kg) | 1665 |
| Fuel Tank Capacity (L) | 42 |
| Additional Features | |
| Information | Heavy Duty Front Axle Support, Softek Clutch, Multisensing Hydraulics with DRC Valve, Tipping Trailer Pipe, Neutral Safety Switch, Clutch Safety Lock, Antiglare Rear View Mirror, Semi Flat Platform, Polymer Fuel Tank |
| Optional Features | |
| Information | Paddy Special - Double Metal Face Sealing |
